Ottawa, ON -- (SBWIRE) -- 02/19/2020 -- A plethora of literature exist that offer plausible information regarding the exceptional performance of sensors based on carbon nanotubes (CNT) transistors, with promises of transformative impact. Indeed, CNT-based biosensors have received immense attention over the decades, following which numerous demonstrations of sensors that make use of nanotubes as the semiconducting channel in a carbon nanotube field-effect transistor (CNTFET) have been exhibited.
Regardless of such strong research activity, fundamental understanding of how CNTFETs respond when operated under bias stress conditions relevant to many sensor applications is still missing. In fact, little has been done to explore bias stress for CNTFETs with channels of one or a few parallel CNTs, with existing reports primarily focusing on gate bias stress, rather than the combination of gate and drain bias stress that is required for most device applications. This lack of information regarding the effects of bias stress on CNTFETs over long time scales is an obstacle to the field.
In a recent publication featured in Advances in Engineering and selected as a key scientific article, Duke University researchers: Steven Noyce (PhD candidate), James Doherty (PhD Student), Dr. Zhihui Cheng, and Prof. Aaron Franklin in collaboration with Dr. Hui Han and Dr. Shane Bowen at Illumina, Inc. developed a measurement platform that allowed for robust, long-term testing of numerous CNTFETs concurrently in a fully automated manner. In addition, they also established bias ranges under which CNT transistors could operate continuously for months or more without degradation. Their work is currently published in the research journal, Nano Letters.
In brief, the team employed a custom characterization system from which they were able to determine the impacts of defect formation and charge traps on the stability of CNT-based sensors under extended bias. In addition to breakdown (which is well-known), they identified three additional operational modes: full stability, slow decay, and fast decay. These four distinct operational modes were based on applied drain-source bias, wherein devices held at sufficiently low voltage exhibited stability for months of continuous operation. Moreover, they established that as the applied bias increased beyond the full stability range, the CNTs experienced irreversible slow and then fast decay until eventually breaking down.
The researchers also identified a current drift behavior that reduced dynamic range of a CNT-based sensor by over four orders of magnitude but could be avoidable with appropriate sensing modalities. Hence, the importance of operating voltages and related device configuration is high for properly functioning CNTFETs being applied to sensing applications. The structure used for the study was chosen to be similar to a majority of previously studied CNT-based sensors so that the results achieved could have close applicability to the field as a whole.
"Carbon nanotube-based sensors have been studied for decades, but mostly with a focus on unique ways to integrate or apply them for a given application," said Prof. Franklin whose lab led the research to Advances in Engineering. "This study digs deeper into the operation of the nanotubes themselves when they are held under prolonged electrical stress, which is often required for sensing applications. Our findings show great promise for using the nanotubes, but with certain constraints that must be factored in when determining how to bias them in a sensor."
In summary, an electrical characterization platform that allows for the long-term interrogation of CNTFETs under various bias conditions was developed. Ultimately, the results presented describe what behaviors are to be expected when CNTs are stressed by continuous and variable biases over long periods of time and demark conditions under which the CNTs are electrically stable, providing valuable insight for the further advancement of the thousands of diverse CNTFET-based sensors that have been proposed. Further, the electrical characterization platform developed in the work is more broadly applicable to other nanoelectronic devices that require long-term study under various bias conditions.
This story has been featured at Advances in Engineering: https://advanceseng.com/are-carbon-nanotubes-stable-enough-for-use-in-sensors/
